AMI-II Powercon Specific is an advanced online analyser for continuous monitoring of specific conductivity in high-purity water systems.
The AMI-II Powercon Specific is a complete system for continuously measuring specific, or total, conductivity in high-purity water. It incorporates the dedicated AMI-II Powercon transmitter, a high-accuracy conductivity sensor, flow cell and digital sample flow meter. Selectable temperature compensation accommodates different sample qualities and alkalising agents, while automatic zero verification supports ongoing measurement accuracy. Designed for power generation, industrial facilities and water treatment applications, the analyser delivers dependable, automatic and virtually maintenance-free operation.
Key Features
- Selectable temperature compensation accommodates different sample qualities and alkalising agents.
- Automatic zero checking uses an integrated high-precision resistor to support measurement accuracy.
- Two-electrode titanium conductivity sensor with a precise cell constant and integrated Pt1000 temperature probe.
- Patented slot-lock sensor design enables fast installation and simple sensor removal.
- Integrated needle valve and digital flow meter support straightforward, dependable operation.
- Factory wet bench-tested and supplied ready for installation and operation.
AMI-II Powercon Specific Specifications
The AMI-II Powercon Specific combines the AMI-II Powercon transmitter, UP-Con1000-SL conductivity sensor and QV-Flow UP-CON-SL flow cell. The complete analyser is assembled on a stainless steel panel and supplied ready for installation and operation.
The transmitter provides two signal outputs for measured values or continuous control, two relays that can be configured as limit switches or controllers, an alarm relay for collective alarm indication and an input for a potential-free contact.
The flow cell incorporates a manual flow adjustment valve and digital sample flow meter.
Measuring range
| Conductivity | 0.055 µS/cm to 30 mS/cm |
Sample conditions
| Temperature | 0 to 50 °C |
| Inlet pressure | Maximum 2 bar |
| Outlet pressure | Pressure-free |
Sample connections
| Inlet | Swagelok ¼" tube adapter |
| Outlet | ⅛" adapter for flexible tube, 8 mm diameter |
| Power supply | 100–240 VAC (±10%) or 10–36 VDC |
Contact us to place an order.
